Tire Size | Ply Rating | Type | Tread Depth | Standard Rim | Available Rim | Inflated Dimensions | Load Capacity | ||||||
Overall Width | Overall Diameter | Max Load kg | Inflation Kpa | ||||||||||
TT | TL | mm | inch | mm | inch | mm | inch | ||||||
9.5L-15 | 6/8 | TL | 7.0 | 0.28 | 8LB | —— | 240 | 9.45 | 765 | 30.12 | 895 | 190 | |
1100 | 280 | ||||||||||||
10.0-15 | 6 | TL | 9.0 | 0.35 | 9.00X15.3 | —— | 264 | 10.39 | 760 | 29.92 | 1110 | 230 | |
8 | 1330 | 310 | |||||||||||
11L-15 | 6 | TT | TL | 7.0 | 0.28 | W8L | 10LB、8LB、W10L | 280 | 11.02 | 775 | 30.51 | 950 | 170 |
8 | 1130 | 220 | |||||||||||
10 | 1285 | 280 |
